190P Motion Pasted
SKU
28312
- Semi traction battery TAB Motion Pasted 190P
- DIN: 96801
- 12V 225Ah/20h
- Dim. 518x273x214/241 mm
- B0 – 3
TAB Motion Pasted is a flooded small traction battery with positive pasted plates (expanded or gravity casted).
Advantages:
Suitable applications:
Charging profiles:
Number of cycles: 300 (IEC / EN 60254-1 / 25°C)
Advantages:
- Excellent vibration resistance
- High rate discharge capability
- High performance in difficult working conditions
- Economical and reliable
Suitable applications:
- Wheelchairs
- Truck applications
- Caravans and motorhomes
- Battery driven carts
- Boats
- Cleaning machines
- Solar systems
Charging profiles:
- Wa; WoWa, IUIa; WUIa
Number of cycles: 300 (IEC / EN 60254-1 / 25°C)
| Weight (kg) | 60,80 |
|---|---|
| Brand | TAB |
| Technology | Wet |
| Voltage (V) | 12V |
| Capacity Ah/20h | 225 |
| Capacity Ah/5h | 190 |
| Box type | C |
| Length (mm) | 518 |
| Width (mm) | 273 |
| Height (mm) | 214 |
| Height terminal (mm) | 241 |
| Base hold down | B0 |
| Layout | 3 |
| Pcs/pallet | 18 |
