Fronius HF charger 12V 20A Selectiva 1kW (230V) New Generation
SKU
24530
Fronius 12V 20A Selectiva 1kW New Generation high frequency charger (230V - mains current 2A). With the Selectiva 1kW battery charger, Fronius offers an efficient and reliable solution for charging 24V traction batteries.
Fronius 12V 20A Selectiva 1kW New Generation high frequency charger (230V - mains current 2A). With the Selectiva 1kW battery charger, Fronius offers an efficient and reliable solution for charging 24V traction batteries. The intelligent Active Inverter Technology and the innovative Ri charging process take into account the individual condition of each battery during charging, increasing its service life and saving energy in the process. The LED lights on the charger easily show the user the state of charge of the battery so they can chose the most charged that will therefore run for the longest time.
Features:
Features:
- Compact dimensions and low weight for flexible application options
- Optimised charging process for maximum energy efficiency and lower enery costs<\li>
- Conservation charging minimises the risk of self discharge, even during longer periods of non-use
- High performance: optimal use of battery capacity
| Weight (kg) | 2,00 |
|---|---|
| Brand | Fronius |
| Voltage (V) | 12V |
| Current (A) | 20 |
| Batterycapacity Ah/5h 7-9h | 135 - 195 |
| Batterycapacity Ah/5h 10-12h | 225 - 280 |
| Batterycapacity Ah GEL (12-14h) | 120 - 160 |
| Length (mm) | 247 |
| Width (mm) | 162 |
| Height (mm) | 88 |
| Cabinet type | 1 kW |
| Mains Voltage | 220V |
| Mains Current | 3A |
| Suited for battery type | Lead acid (Wet, gel, AGM, EFB) |
| High frequency or conventional technology | HF |
| Protection class | IP40 |
